2026 Fiberglass Shaking Table for Tungsten Ore: How to Choose the Right Model and Price

2026-06-01

SHARE TO:

If you’re in the tungsten ore processing game, you’ve probably heard that shaking tables are still the go-to for fine particle recovery. But with 2026 models hitting the market, especially fiberglass ones, the choices can make your head spin. Don’t worry—I’m here to break it down in plain, down-to-earth language. Whether you’re a mine owner, a purchasing manager, or a greenhorn technician, this article will help you pick the right model without burning a hole in your pocket.

Let’s dive in.

What Is a Fiberglass Shaking Table?

Simply put, a fiberglass shaking table is a piece of gravity separation equipment. It uses water flow and shaking motion to separate heavy tungsten ore from lighter waste rock. The fiberglass deck is a game-changer because it’s lighter, more durable, and corrosion-resistant compared to old-school steel or wooden decks.

You’ll find these tables in small to medium-scale tungsten operations, often paired with jigs or spirals for a complete circuit.

Real-World Examples: Who’s Using Them?

Case 1 – A small tungsten mine in Jiangxi, China:
A miner processing 10 tons of scheelite per day switched from a traditional steel table to a fiberglass model from Jiangxi Hengchang Mining Equipment. Recovery jumped from 65% to 82% on the -200 mesh fraction. The owner said maintenance costs dropped by half.

Case 2 – A tungsten operation in Myanmar:
They used a 6-S type fiberglass table for wolframite recovery. With daily capacity around 15 tons, they achieved a concentrate grade of 65% WO3. The table handled both coarse (0.5mm) and fine (0.074mm) material well.

These are not lab experiments—they’re real operations making real money.

How Does It Work?

Gravity separation, but smarter. Here’s the 30-second version:

A slurry of tungsten ore and water feeds onto the table deck.
The deck shakes back and forth (asymmetric motion) while water flows across it.
Heavy tungsten particles move along the riffles toward the concentrate end.
Light gangue minerals wash off the side as tailings.

The key? The water flow rate and shake speed. Adjust those, and you’ll cut cleaner concentrates.

Key Structural Features to Look For

Fiberglass deck: Lightweight (about 30% lighter than steel), rust-free, and smooth for better flow.
Adjustable stroke: Turn a handwheel to change the shaking length (8-20 mm is standard).
Riffle profile: Choose between coarse (for +0.5mm) or fine (for -0.074mm) patterns.
Motor mount: Look for easy access to change belts or motor quickly in the field.

Pro tip: Ask the factory for a color-coded control panel. Trust me, it’ll save your night shift crew from guessing.

What Ores Can a Fiberglass Shaking Table Handle?

You’re in luck—these tables are versatile. For tungsten specifically:

Scheelite (CaWO4): Works great on fine fractions (0.074-1mm).
Wolframite (Fe,Mn)WO4: Handles coarser particles (up to 2mm) with high efficiency.
Mixed tungsten ore: Combine with a magnetic step if you have both scheelite and wolframite.

Other compatible ores include gold, tin, tantalum, and coltan—but today we’re talking tungsten.

Advantages Over Other Equipment

Feature	Fiberglass Shaking Table	Old Steel Table	Spiral Classifier
Weight	~200 kg	~400 kg	Heavy
Corrosion resistance	High	Low	Medium
Fine recovery (<0.074mm)	Excellent	Good	Poor
Price (range)	$2,500-$5,000	$3,500-$6,000	$4,000-$8,000
Maintenance	Easy	Frequent	Moderate

For tungsten fines, shaking tables beat spirals every time.

Processing Capacity (Real Numbers)

Let’s get specific for tungsten ore (density ~6.5 g/cm³):

Model	Deck Area	Feed Size	Capacity t/h	Water Use (m³/h)
6-S 1100x500	0.55 m²	-2mm	0.3-0.5	0.8-1.2
6-S 2100x1050	2.2 m²	-1mm	0.8-1.5	2.5-4.0
6-S 2700x1200	3.2 m²	-0.5mm	1.5-2.5	4.0-6.0

Note: These are real feed rates for tungsten, not lab-promo numbers. Adjust for moisture content.

Daily Operation & Maintenance Tips

Operation:

Start water first, then feed slurry.
Adjust stroke length 8-15 mm for coarse tungsten; 10-20 mm for fines.
Check concentrate color every 15 minutes—pure tungsten is dark grey to black.

Maintenance:

Wash the deck daily with clean water to prevent buildup.
Lubricate the eccentric shaft weekly.
Check belts every month—loose belts kill efficiency.
ｒｅｐｌａｃｅ deck surface every 12-18 months (depends on wear).

Pro tip: Keep a spare set of deck riffles—they’re cheap and save a shift when a rock jams.

How to Choose the Right Model for Your Tungsten Operation

Follow this simple rule:

Feed size >1mm → Choose a coarse riffle model (like 6-S 2100 with 18mm riffles).
Feed size <0.3mm → Go fine riffle (6-S 2700 with 8mm riffles).
Daily tonnage <10 tons → A 6-S 1100 is plenty.
10-30 tons/day → Two 6-S 2100 tables in parallel.
Cost-sensitive → Fiberglass models from Jiangxi Hengchang Mining Equipment are usually 15-20% cheaper than comparable brands, with similar specs.

Remember: Don’t over-buy capacity. A table running at 70% load gives the best recovery.

Price Range for 2026 Models

Prices vary wildly, but here's a market snapshot for fiberglass shaking tables:

Model	Price Range (USD)	Typical Manufacturer
6-S 1100x500	$1,800 - $2,800	Jiangxi Hengchang, others
6-S 2100x1050	$3,200 - $4,500	Same
6-S 2700x1200	$4,500 - $6,500	Same

For a 6-S 2100 fiberglass table with adjustable stroke and fine riffles, expect to pay around $3,800-$4,200 CIF for a standard order. If you buy directly from Jiangxi Hengchang Mining Equipment, you might get a better warranty (1-year full coverage is the norm).

Final Practical Advice

If I were buying for a tungsten operation today:

Pick fiberglass – Lighter, cheaper, and lasts longer in fine ore setups.
Go for an adjustable stroke model – It’s only $200-$300 more, but you’ll adapt easily when ore changes.
Run two smaller tables – Instead of one giant one. If one breaks, you’re not shut down.
Talk to a factory sales engineer – Not a sales rep. Engineers will tell you the real limitations.

Bottom line: A fiberglass shaking table is still the king for tungsten fine recovery in 2026. Don’t overcomplicate it—match the model to your feed size and tonnage, and you’ll be pulling concentrate in no time.

Got questions about sizing? ｄｒｏｐ a comment or check out the catalog from Jiangxi Hengchang Mining Equipment—they’ve got a model for every tungsten scenario.
