Chinese
周期式搅拌球磨机是一种湿式超细粉碎设备。适用于磁性材料、粉末冶金、涂料、油漆等物料的超细粉碎。该机体积小，重量轻，能量密度大，粉碎效率高。同时它采用定时循环磨料，保证了生产工艺的稳定。
Cycle agitating mill is a kind of wet superfine crushing equipment which applies to ultrafine crushing of materials such as magnetic materials, powder metallurgy, coating, and paint. This machine features small size, light weight, high energy density, and high crushing efficiency. Besides, it grinds materials circularly to ensure stable production process.
| 型号规格 Model | 单位 Uite | ZJM-1000 |
| 转速（低速） Speed（Low） | r／min | 14 |
| 转速（高速）Speed（High） | r／min | 57 |
| ****装料量 Capacity | kg | 400 |
| 进料粒度 Feed size | mm | 0.074 |
| 出料粒度（４小时后）Output size | um | ＜1.5 |
| 主机功率Power | kw | 15／37 |
| 泥浆泵功率 Pump power | kw | 3 |
| 有效容积Volume | L | 965 |
| 外形尺寸 Overall dimensions | mm | 2075×1620×312 |
| 重量 Weight | kg | 4500 |
