ZJM搅拌球磨机是一种实验室超细粉磨装置，其结构合理、操作方便、高效节能。主要适应于化工、磨料、陶瓷、涂料、粉末冶金、磁性材料等各种行业的物料超细粉磨试验加工。
ZJM agitating mill is a type of laboratory superfine pulverizing device. It is reasonably structured, easy to operate, efficient, and energy saving. It mainly applies to superfine pulverization of materials in various industries such as chemical, grinding material, ceramic, coating, powder metallurgy, and magnetic materials.
| 型号规格Model | 单位 Uite | ZJMΦ150×300 | ZJMΦ250×320 |
| 搅拌桶尺寸 Tank size | mm | Φ150×300 | Φ250×320 |
| 搅拌桶容积 Tank voleme | L | 5 | 15 |
| 搅拌器转速 Tank Speed | r/min | 210 | 42 ～ 415 |
| 给料粒度 Feed size | 目 | ≤ 60 | ≤ 60 |
| 出料粒度 Output size | μ m | ≤ 1 | ≤ 1 |
| 功 率 Power | ke | 1.5 | 3 |
| 外形尺寸 Overall dimensions | mm | 600×350×1000 | 1040×450×1600 |
| 重 量 Weight | kg | 120 | 380 |
