试验室XMCQ-Ф280×290型瓷衬球（棒）磨机技术参

本机是一种新型的实验室磨矿设备。可供冶金、建材、化工、轻工、煤炭、水电、农业、地质、国防等部门实验室作干湿两用磨细某些忌铁污染的矿石和其他物料之用。

Local laboratory is a new kind of grinding equipment. For metallurgy, building materials, chemicals, light industry, coal, hydropower, agriculture, geology, and other departments of national defense laboratory for wet and dry ground of dual-use some of the anti-pollution of iron ore and other materials.

型号规格 Model		单位Uite	XMCQ-Ф180×200	XMCQ-Ф280×290
筒体尺寸 Drum size		mm	Ф180×200	Ф280×290
容积 Volume		L	5.1	17．96
筒体转速 Drum speed		r/min	116	70
磨矿量 Capacity		kg	0.25	3～5
给料粒度 Feed size		mm	-2	-2
排料粒度 Outside size		mm	-0.074	-0.074
功率 Power		kw	0.55	0.75
磨矿瓷球规格	Ф35(mm)	kg	2.8	3.6
	Ф30(mm)	kg	3.6	4.3
	Ф25(mm)	kg	5.6	6.5
外形尺寸 Overall dimensions		mm	1052×613×1160	700×570×1246
质量 Weight		kg	150	185

注：瓷球数量可由用户根据物料的性质和重量适当调整。
