试验室XFG型挂槽浮选机技术参数 Technical Parame

SHARE TO:

Processing Materials Application Range Advantages Product Structure Technical Parameter

该浮选机用于地质、冶金、建材、化工、煤炭、矿山选厂及院校科研单位试验室搅拌、分离、擦洗、精选矿样等。本产品由原地矿部唯一指定企业生产，执行行业标准。

The flotation machines are employed for agitation , separation, scrubbing and cleaning of samples in labs of geological, metallurgical, building material, chemical, coal, beneficiation plant of mine , institutions of higher learning and research institutions. The product is produced by the only manufacturer designated by the former. Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.

XFG型挂槽浮选机XFG Model Hanging Cell Flotation Machine

XFG型挂槽浮选机用于搅拌、擦洗、分离和精选少量矿样等。该机具有浮选速度快和选别指标好等特点。

XFG Model Hanging Cell Flotation Machine is used for agitation separation, scrubbing and cleaning of minor samples with rapid speed of flotation and desirable separation indexes and other features.

型号规格 Model	容量 Capa.	选槽容积 Volume	叶轮直径 Impeller diameter	叶轮转速 Impeller speed	给矿粒度 Feed size	功率 Motor power	质量 Weight
型号规格 Model	g	ML	mm	r/min	mm	w	kg
XFG 5 -35克	5、15 25、35	20、60 100、140	Φ20、Φ26、Φ30	1000-1850	≤0.2	90	15
XFG 50 -100克	50、100	200 400	Φ36、Φ48	1000-1850	≤0.2	90	16
XFG 250 -500克	250、500	1000 2000	Φ60、Φ64	1500、2000	≤0.2	250	25
XFG 1000克	1000	4000	Φ80	900、1500	≤0.2	250	27
