·GX型高效中心传动浓缩机 High-effiency thickener se

GX型高效中心传动浓缩机 High-effiency thickener series

型号 规格 Model	浓密池尺寸 Dia. of the tank	耙子转速 Speed	提耙高度 Lifting height	处理能力 Capacity	功率Power	质量 Weight
	m	r/min	mm	t/h	kw	t
GX2.5	Φ2.5×1.73	1.68	200	≤1	0.75	4
GX3.6	Φ3.6×1.98	1.10	200	≤1.2	0.75	5
GX5.18	Φ5.18×2.38	0.80	300	≤3.75	1.5	10
GX6	Φ6×2.96	0.30	300	≤4	2.2	10.5
GX7	Φ7×3	0.30	300	≤7.3	2.2	12.2
GX8	Φ8×3.32	0.25	300	≤8	2.2	13.8
GX9	Φ9×3	0.47	400	≤8.75	3	14.6
GX12	Φ12×3.6	0.30	400	≤15	4	16
GX15	Φ15×4	0.20	400	≤24	4/2.2	19
GX18	Φ18×4.4	0.13	500	≤40	5.5/2.2	21
GX20	Φ20	0.145	400	≤45	5.5/2.2	22
GX21	Φ21×4.4	0.10	500	≤60	5.5/2.2	24
GX24	Φ24×4.4	0.09	500	≤80	2×2.2/4	26
GX30	Φ30	0.069	600	≤96	2×2.2/4	29
GNZ2	Φ2×1.8	1.17	160	＜0.9	1.1	2.23
GNZ3	Φ3.6×1.7	1.10	200	＜1	1.5/0.75	3.17
GNZ5	Φ5.18×2.13	0.80	300	＜3.75	4/0.75	3.68
GNZ9	Φ9×2.8	0.427	300	＜8.75	3/2.2	14.6
GNZ12	Φ12×3.6	0.35	500	＜15	3/2.2	16
GNZ15	Φ15×3.8	0.35	500	＜24	4/2.2	19
GNZ18	Φ18	0.193	500	≤40	5.5/2.2	21
GNZ20	Φ20	0.145	600	≤45	5.5/2.2	22
GNZ24	Φ24	0.085	600	≤80	2×2.2/4	26
GNZ30	Φ30	0.069	600	≤96	2×2.2/4	29
