TZD型重力胶带斗式提升机 Heavy belt bucket elevator

型号规格	宽度	头部滚筒直径	尾部滚筒直径	带速	头轴转速	钢制料斗			塑料料斗
						斗容	斗距	输送量	斗容	斗距	输送量
	mm	mm	mm	m/s	r/min	L	mm	t/h	L	mm	t/h
TZD200	200	630	500	1.76	53.5	1.21	300	10	1.21	300	10
				176	53.5		150	20		150	20
				2	60		125	30		125	30
				2.75	83.3		105	50		105	50
TZD250	250	630	500	1.76	53.3	2.35	150	30	2.35	150	30
				1.76	53.3		125	50		125	50
				2.42	73.5		125	80		125	80
				3	91.9		125	100		125	100
TZD300	300	710	565	1.93	52.5	6	215	80	3.1	145	50
				2.2	60		215	100		145	80
				3.05	82.2		215	150		145	100
TZD400	400	710	565	1.93	52.5	8.4	215	100	6.1	195	80
				2.2	60		215	150		195	100
				3.05	82.2			200			150
TZD500	500	800	655	1.97	47	10.9	215	150	11.5	255	100
				2.2	52.8			200			150
				3.1	74			300			200
TZD650	650	800	655	2.2	52.8	2×6	215	200	2×3.1	145	150
				2.76	66			300			200
				3.87	92.5			400			300
TZD800	800	1140	930	2.5	41.6	2×8.4	215	400	2×6.1	195	200
				3.15	52.8			500			300
				3.94	66			600			400
TZD1000	1000	1140	930	2.5	41.5	2×10.9	215	500	2×11.5	255	400
				3.15	52.8			600			500
				3.94	66			800			600

TZD型重力胶带斗式提升机 Heavy belt bucket elevator
